| Brand Name: | Wellman |
| Model Number: | X8800 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Brand | Japan Hamamatsu |
| Type | Closed, microfocus |
| Max tube voltage | 90KV |
| Max tube current | 200μA |
| Focal spot size | 5μm |
| Function | Auto preheat |
| Effective area | 130mm*130mm |
| Pixel size | 85μm |
| Resolution | 1536*1536 |
| Frame rate | 20fps |
| Tiltable angle | ±45° |
| Rotation angle | 360° |
| Size | 400mm*400mm |
| Detectable area | 400mm*400mm |
| Max load | 10kg |
| Magnification | Geometry 200X | System 1500X |
| Inspection speed | Max 3.0s/point |
| Dimensions | 1550mm(L)*1600mm(W)*1700mm(H) |
| Weight | 1800kg |
| Power supply | AC110-220V 50/60HZ |
| Max power | 1800W |
| Industrial PC | 15 CPU,8G RAM,240GB SSD |
| Displayer | 24"HDMI LCD |
| Radiation leakage | No leakage, international standard: ≤1μSv/h |
| Lead glass observation window | Transparent lead glass window shields radiation to observe the inner status |
| Window and back door safety interlock | Once users open the window or back door, X-ray tube will power off immediately. When the window or back door is open, users can't turn on the X-ray |
| Electromagnetic safety switch | Lock once the X-ray is on, users can't open the observation window |
| Emergency stop | Next to the operation position, press to power off |
| Tube protection | User can't leave the software if you don't close the X-ray tube |
