| Brand Name: | WELLMAN |
| Model Number: | X-ray reel Counter XC - 01 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | Worldwide supply |
The XC-O1 Automatic X-ray Reel Counter delivers exceptional counting accuracy through advanced scanning technology and AI-powered algorithms, making it ideal for high-volume electronic component manufacturing environments.
| Type | Integrated, microfocus |
| Max tube voltage | 80kV |
| Max tube current | 700μA |
| Focal spot size | 30μm |
| Type | Super definition digital FPD |
| Effective area | 430mm × 430mm |
| Pixel size | 139μm |
| Resolution | 3072 × 3072 |
| Max size | 17" (430mm) |
| Max thickness | 88mm |
| Min parts size | 01005 |
| Speed | 7-10 seconds |
| Accuracy | 01005 ≥ 99.98%, 0201 & above ≥ 99.99% |
| Dimensions | 1000mm (L) × 1300mm (W) × 1820mm (H) |
| Weight | 580kg |
| Power supply | AC110-220V 50/60HZ |
| Max power | 800W |
| Industrial PC | I7 CPU, 16G RAM, 256G SSD+4T HDD |
| Displayer | 24" HDMI LCD |
| Auto code scanning | Barcode and QR code |
| Label printing | Prints corresponding label when user takes out a reel |
| Counting record | Inquiry by time range, work order number |
| Management system connection | MES, ERP, WMS etc. |
| Mode switching | No need to switch single/multi reel mode |
| Work order no. | Support work order number recording |
| Radiation leakage | No leakage, international standard: ≤1μSv/h |
| Back door safety interlock | X-ray tube powers off immediately when back door opens |
| Anti-pinch | Safety light curtain covers entire drawer, stops immediately when obstruction detected |
| Emergency stop | Located at front operation position for immediate power cutoff |
| Reel size | Parts size | Quantity | Accuracy | Speed |
|---|---|---|---|---|
| 7" (180mm) | 01005 | 40000 | 99.98% | 9-10s |
| 7" (180mm) | 0201 | 20000 | 99.99% | 8-9s |
| 7" (180mm) | 0402 | 10000 | 99.99% | 7-8s |
| 7" (180mm) | 0603 | 5000 | 99.99% | 7-8s |
| 10" (254mm) | 1206 | 5000 | 99.99% | 7-8s |
| 15" (380mm) | 1206 | 10000 | 99.99% | 7-8s |
Our counting software utilizes a powerful artificial intelligence deep learning algorithm that automatically identifies components and applies appropriate algorithms without manual binding. The AI learns from counted component data including:
As counting operations increase, the system becomes progressively more accurate. The algorithm easily adapts to similar components or larger trays, ensuring consistent performance across varying requirements.
Every Wellman X-ray counter connects to our cloud database, automatically uploading machine data and images while downloading the latest database updates. Our engineering team continuously optimizes algorithms based on collected data, providing regular cloud database updates for all customers.
This continuous improvement cycle ensures counting accuracy approaches 100% over time while expanding component type coverage. When encountering new components, the system can instantly access stored data from our database, delivering higher efficiency, accuracy, and broader coverage.
