Name: SMT Lines Auto Splicer Machine Auto Reel Splicing Machine 150W
Brand: SHENZHEN WEIMING PHOTOELECTRIC CO.,LTD.
SKU: RS-1000
Availability: InStock

Brand Name:	WELLMAN
Model Number:	RS-1000
MOQ:	1
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE FDA

Charge Power Supply:

220V 50Hz

Camera:

Left, Right 130W Pixel Camera

Power Rating:

150W

Per Pass Rate:

≥97％

Mechanicalness Noise:

50 Decibel

Highlight:

SMT Lines auto splicer machine

SMT Lines Reel Splicing Machine

150W auto splicer machine

Product Description

SMT Auto Reel Splicing Machine RS-1000

Key Advantages

Simple Operation: New operators can achieve proficiency within 10 minutes, reducing machine downtime and improving efficiency
Labor Savings: One operator can manage two SMT lines simultaneously
Precision Detection: CCD optical system automatically detects material presence and accurately calibrates cut positions
Material Recovery: Single-button operation for automatic material belt recycling after connection
High Efficiency: Completes connections in just 10 seconds with 98% success rate
Error Prevention: Integrated barcode scanning system prevents material mismatches

Specifications

Dimensions	550mm * 470mm * 1300mm (LWH, including scanner)
Work Height	890mm
Connection Cycle	10 seconds (including material collection and detection)
Connection Precision	0.08mm
Power Source	18650 battery pack DC 36V (12-14 hours operation)
Camera System	Dual 130W pixel cameras with LED white light source
Success Rate	≥97%
Operating System	Industrial PC with 10.1" touch display, Windows 10
Weight	62kg (excluding battery)

Material Compatibility

Compatible with paper and adhesive type materials, width 8mm, thickness 0.25-1.3mm. Handles 99% of market-available materials (special materials require confirmation).

System Components

Main Structure
