150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time

150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time

Brand Name: WELLMAN
Model Number: RS-1000
MOQ: 1
Payment Terms: T/T
Detail Information
Place of Origin:
CHINA
Certification:
CE FDA
Charge Power Supply:
220V 50Hz
Camera:
Left, Right 130W Pixel Camera
Power Rating:
150W
Per Pass Rate:
≥97%
Mechanicalness Noise:
50 Decibel
Highlight:

150W Automatic Splicing Machine

,

SMT Automatic Splicing Machine

,

SMT Auto Reel Splicing Machine

Product Description
Revolutionize Your SMT Process with Automatic Splicing Machine for Improved Efficiency
SMT Auto Reel Splicing Machine RS-1000
Key Advantages
  • Simple Operation: New operators can achieve proficiency within 10 minutes, reducing machine downtime and improving efficiency
  • Labor Savings: One operator can manage two SMT lines simultaneously
  • Precision Detection: CCD optical system automatically detects material presence and accurately calibrates cut positions
  • Material Recovery: Single-button operation for automatic material belt recycling after connection
  • High Efficiency: Completes connections in just 10 seconds with 98% success rate
  • Error Prevention: Integrated barcode scanning system prevents material mismatches
Specifications
Dimensions 550mm * 470mm * 1300mm (L*W*H, including scanner)
Work Height 890mm
Connection Cycle 10 seconds (including material collection and detection)
Connection Precision 0.08mm
Power Source 18650 battery pack DC 36V (12-14 hours operation)
Camera System Dual 130W pixel cameras with LED white light source
Success Rate ≥97%
Operating System Industrial PC with 10.1" touch display, Windows 10
Weight 62kg (excluding battery)
Material Compatibility
Compatible with paper and adhesive type materials, width 8mm, thickness 0.25-1.3mm. Handles 99% of market-available materials (special materials require confirmation).
Main Structure
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 0
Main Structure
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 1
Rail Transfer Structure
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 2
Spindle Structure
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 3
Operation Interface
Performance Comparison
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 4
Time Comparison
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 5
Effectiveness Comparison
Software Features
150W Automatic Splicing Machine SMT Auto Reel Splicing Machine With 10s Cycle Time 6
Software Interface
