| Brand Name: | HAMAMATSU |
| Model Number: | V10905P |
| MOQ: | 1 |
| Payment Terms: | T/T |
| X-ray I.I. Parameters | ||
|---|---|---|
| Input window material (Thickness) | Aluminum(t0.5mm) | - |
| Input phosphor material | Csl | - |
| Output phospho material | P43 or equivalent | - |
| Input surface field-of-view size | 4 inch mode: φ99 mm 2inch mode: φ50 mm |
mm |
| Output image size | φ20 | mm |
| Resolution (on input surface)(Typ.) | 4 inch mode: 100 Lp/cm 2inch mode: 110 Lp/cm |
Lp/cm |
| Conversion factor | 3.4 | cd/m²/uGy/s |
| Shading (Min.) | 60 | % |
| Contrast ratio | 14 | - |
| Operating ambient temperature | +10 to +40 | °C |
| Storage temperature | -10 to +45 | °C |
| Operating and storage humidity | Below 85% (no condensation) | - |
| Weight | Approx. 8.0 | kg |
| Power supply Parameters | ||
| Input voltage(AC) | 100 to 240 | V |
| Output voltage(DC) | 24 | V |
| Power consumption | 30 | VA |
| Weight | Approx. 0.5 | kg |
