| Brand Name: | WELLMAN |
| Model Number: | T-130A |
| MOQ: | 1 |
| Payment Terms: | T/T |
Technical Specifications
Ray source parameter
| Type of ray tube | Closed tube X-ray source |
|---|---|
| Tube voltage range | T-130A:40-130 KV |
Detector parameter
| Detector type | Amorphous silicon flat panel detector |
|---|---|
| Pixel size | T-130A:100μm |
| Pixel matrix | T-130A:1536x1536 |
| Maximum placement sample size | T-130A:diameter 400mm × height 600mm |
|---|---|
| Maximum imaging area | T-130A:diameter 200mm × height 300mm |
| JIMA card resolution | 3μm |
| Equipment weight | T-130A:1T |
| Equipment size | T-130A:1370mm × 850mm × 1770mm (Length×width×height) |
