| Brand Name: | WELLMAN |
| Model Number: | T-160 |
| MOQ: | 1 |
| Payment Terms: | T/T |
Ray Source Parameters
| Type of ray tube | Closed tube X-ray source |
|---|---|
| Tube voltage range (T-160) | 0-150KV |
Detector Parameters
| Detector type | Amorphous silicon flat panel detector |
|---|---|
| Pixel size (T-160) | 139μm |
| Pixel matrix (T-160) | 1536x1536 |
Equipment Performance Parameters
| Maximum sample size (T-160) | Diameter 500mm * Height 750mm |
|---|---|
| Maximum imaging area (T-160) | Diameter 250mm * Height 160mm |
| JIMA card resolution | 3μm |
| Equipment weight (T-160) | 1.5T |
| Equipment dimensions (T-160) | 1850mm * 1300mm * 2100mm (L*W*H) |
| Imaging software system | Integrated scanning imaging software, 3D image reconstruction software, 3D image measurement and analysis software, image database management software |
