| Brand Name: | WELLMAN |
| Model Number: | X-ray X8800 |
| Payment Terms: | T/T |
| X-ray Source | |
| Type | Open, microfocus |
| Max Tube Voltage | 160kV |
| Max Tube Current | 500μA |
| Target Power | 15W |
| Tube Power | 65W |
| Focal Spot Size | 1μm |
| Flat Panel Detector | |
| Effective Area | 130mm×130mm |
| Pixel Size | 49.5μm |
| Resolution | 1536×1536 |
| Frame Rate | 20fps |
| Tiltable Angle | 60° |
| Rotation Angle | 360° |
| Table | |
| Size | 400mm×400mm |
| Detectable Area | 400mm×400mm |
| Max Load | 10kg |
| Equipment | |
| Geometry Magnification | 2500X |
| Inspection Speed | Max 3.0s/point |
| Dimensions | 1550mm (L) × 1600mm (W) × 1700mm (H) |
| Weight | 1800kg |
| Power Supply | AC110-220V 50/60HZ |
| Max Power | 1800W |
| Industrial PC | I7 CPU, 16G RAM, 240GB SSD+1TB HDD |
| Displayer | 24" HDMI LCD |
| Safety Features | |
| Radiation Leakage | No leakage, international standard: ≤1μSv/h |
| Lead Glass Observation Window | Transparent lead glass window shields radiation while allowing internal observation |
| Window and Back Door Safety Interlock | X-ray tube powers off immediately when window or back door is opened |
| Electromagnetic Safety Switch | Locks when X-ray is active, preventing window access |
| Emergency Stop | Located near operation position for immediate power cutoff |
| Tube Protection | Software prevents leaving without proper X-ray tube shutdown |
| Function Module | Operation |
| X-ray Tube Control | Mouse-click operation for power control with real-time voltage/current display and adjustment |
| Status Bar | Visual indication of interlock status, pre-heat status, and X-ray status |
| Image Effect Adjustment | Adjustable brightness, contrast and gain for optimal image quality |
| Product List | Save and recall inspection parameters for improved efficiency |
| Navigation Window | Click-to-move functionality for precise table positioning |
| Motion Axis Status | Real-time coordinate display |
| Inspection Result | Organized display of measurement results including voids rate, distance, area |
| Speed Control | Adjustable movement speed for each axis (slow, normal, fast) |
| Voids Rate Measurement | Automatic calculation of solder ball voids, area, circumference with NG/OK indication |
| Other Measurement Functions | Distance, distance rate, angle, radius, perimeter measurements for comprehensive analysis |
| Automatic Inspection | Manual setting, array configuration, and automatic identification of inspection points |
