| Brand Name: | WELLMAN |
| Model Number: | X-6800 |
| Payment Terms: | T/T |
| Function Module | Description |
|---|---|
| X-ray Tube Control | Mouse-click operation with real-time voltage/current display and adjustment |
| Status Bar | Visual indication of interlock, pre-heat, and X-ray status |
| Image Effect Adjustment | Brightness, contrast and gain adjustment for optimal imaging |
| Product List | Save and recall inspection parameters for efficiency |
| Navigation Window | Click-to-move table positioning with camera guidance |
| Motion Axis Status | Real-time coordinate display |
| Inspection Result | Organized display of measurement results with pass/fail indication |
| Speed Control | Adjustable axis movement speeds (slow, normal, fast) |
| Feature | Description |
|---|---|
| Automatic Calculation | Rectangle-based solder ball analysis with automatic void detection and measurement |
| Parameters Adjustment | Customizable grayscale threshold, pixel, contrast, and size filtering |
| Manual Void Addition | Polygon or free-form drawing for custom void calculation |
| Parameter Saving | Save and recall measurement parameters for consistent results |
| Function | Description |
|---|---|
| Distance | Vertical distance measurement from point to baseline |
| Distance Rate | Percentage ratio measurement for through-hole soldering rate |
| Angle | Angle measurement between defined rays |
| Radius | Circle measurement for round components with circumference and area |
| Perimeter | Square component measurement with length, width and area |
| Mode | Description |
|---|---|
| Manual Setting | Custom inspection point positioning with automatic inspection and image saving |
| Array | Automated grid-based inspection from minimal setup parameters |
| Automatic Identification | Feature-based automatic position detection and measurement |
