| Brand Name: | WELLMAN |
| Model Number: | Ultra-Inline CT/3D |
| MOQ: | 1 |
| Payment Terms: | T/T |
Equipment Performance Parameters
| Maximum possible sample size | 750 mm*530 mm (Length x Width) |
| Maximum imaging area | 730 mm*510 mm (Length x Width) |
| JIMA card resolution | 4μm |
| Equipment weight | 5T |
| Equipment size | 2336 mm*2321 mm*2109 mm (Length * width * height) |
| Imaging software system | A set of online plate CT imaging system, including integrated scanning, data analysis and other modules |
Detector Parameters
| Detector type | Amorphous silicon flat panel detector |
| Pixel size | 49.8 μm |
| Pixel matrix | 2304*2813 |
| Effective imaging area | 115 mm*140 mm |
| Picture frame rate | 18 fps (1*1) |
X-ray Source Parameters
| X-ray Tube Type | Closed-tube X-ray source |
| Tube voltage range | 45-130 KV |
| Tube current range | 0-0.5 mA |
| Maximum operating power | 65W |
