| Brand Name: | WELLMAN |
| Model Number: | XC-01 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | Worldwide supply |
| Type | Closed, microfocus |
| Focal Spot Size | 30μm |
| Max Tube Voltage | 80kV |
| Max Tube Current | 700μA |
| Type | Super definition digital FPD |
| Pixel Size | 139μm |
| Effective Area | 430mm × 430mm |
| Resolution | 3072 × 3072 |
| Max Thickness | 88mm |
| Min Parts Size | 01005 |
| Max Size | 17" (430mm) |
| Speed | 7-10 seconds |
| 01005 | ≥ 99.98% |
| 0201 & above | ≥ 99.99% |
| Dimensions | 1000mm (L) × 1300mm (W) × 1820mm (H) |
| Weight | 580kg |
| Power Supply | AC110-220V 50/60HZ |
| Max Power | 800W |
| Processor | I7 CPU, 16G RAM, 256G SSD+4T HDD |
| Display | 24" HDMI LCD |
All Wellman X-ray counters connect to cloud database, automatically uploading data and images while downloading the latest updates. Our engineering team continuously optimizes algorithms using collected data and regularly updates the database for all customers.
Our counting software utilizes advanced AI deep learning algorithms for automatic component identification (no manual binding required) and continuously learns from component data including:
| Reel Size | Parts Size | Quantity | Accuracy | Speed |
|---|---|---|---|---|
| 7" (180mm) | 01005 | 40000 | 99.98% | 9-10s |
| 7" (180mm) | 0201 | 20000 | 99.99% | 8-9s |
| 7" (180mm) | 0402 | 10000 | 99.99% | 7-8s |
| 7" (180mm) | 0603 | 5000 | 99.99% | 7-8s |
| 10" (254mm) | 1206 | 5000 | 99.99% | 7-8s |
| 15" (380mm) | 1206 | 10000 | 99.99% | 7-8s |
