| Brand Name: | WELLMAN |
| Model Number: | X-ray reel Counter XC - 01 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | Worldwide supply |
| Type | Closed, microfocus |
| Max Tube Voltage | 80kV |
| Max Tube Current | 700μA |
| Focal Spot Size | 30μm |
| Type | Super definition digital FPD |
| Effective Area | 430mm × 430mm |
| Resolution | 3072 × 3072 |
| Pixel Size | 139μm |
| Speed | 7-10 seconds |
| Max Size | 17" (430mm) |
| Max Thickness | 88mm |
| Min Parts Size | 01005 |
| Accuracy | 99.99%(01005 ≥ 99.98%) |
| Dimensions | 1000mm (L) × 1300mm (W) × 1820mm (H) |
| Weight | 500kg |
| Displayer | 24" HDMI LCD |
| Power Supply | AC110-220V 50/60HZ |
| Max Power | 800W |
| Industrial PC | I7 CPU, 16G RAM, 256G SSD+4T HDD |
| Auto Code Scanning | Barcode and QR code |
| Label Printing | Prints corresponding label when taking out a reel |
| Counting Record | Inquiry by time range, work order number |
| Management System Connection | MES, ERP, WMS etc. |
| Mode Switching | No need to switch single/multi reel mode |
| Work Order No. | Support |
| Radiation Leakage | No leakage |
| Back Door Safety Interlock | X-ray tube powers off immediately |
| Anti-pinch | Safety light curtain covers entire drawer, stops immediately when obstruction detected |
| Emergency Stop | Located at front operation position, press to power off |
| Reel Size | Parts Size | Quantity | Accuracy | Speed |
|---|---|---|---|---|
| 7" (180mm) | 01005 | 40000 | 99.98% | 9-10s |
| 7" (180mm) | 0201 | 20000 | 99.99% | 8-9s |
| 7" (180mm) | 0402 | 10000 | 99.99% | 7-8s |
| 7" (180mm) | 0603 | 5000 | 99.99% | 7-8s |
| 10" (254mm) | 1206 | 5000 | 99.99% | 7-8s |
| 15" (380mm) | 1206 | 10000 | 99.99% | 7-8s |
