pcb x-ray machine X6800 compressed

PCB X-ray Machine
August 16, 2025
Category Connection: PCB X Ray Machine
Chat Now Contact Us
Tags:
#pcb x ray inspection machine #pcb x ray inspection equipment #smt x ray machine
Brief: In this video, we explore how the X6800 PCB X-ray Inspection Machine's 5-axis system and advanced imaging capabilities deliver precise internal analysis of electronic components. You'll see a demonstration of automated batch inspection, real-time defect identification, and measurement functions for BGA solder voids, IC gold wires, and PCB through-holes, showcasing how its design ensures reliable, high-magnification inspection for industrial applications.
Related Product Features:
  • Closed-type microfocus X-ray tube with over 10,000 hours lifetime and maintenance-free operation.
  • 5-axis linkage system with adjustable speed for precise positioning and inspection.
  • 5-inch high-definition digital flat panel detector (FPD) with 60° tilt capability.
  • Automatic navigation window moves the table to clicked locations for efficient inspection.
  • Programmable inspection procedures enable automated batch inspection for consistent results.
  • Real-time measurement functions for voids rate, distance, angle, and component dimensions.
  • Comprehensive safety features including radiation leakage control and emergency stop button.
  • Intuitive software with quick defect identification, requiring only 2 hours of training.
FAQs:
  • What is the magnification capability of the X6800 PCB X-ray Inspection Machine?
    The X6800 offers a geometric magnification of 200X and a system magnification of up to 1500X, providing detailed internal views of PCBs and components.
  • How does the machine ensure operator safety during X-ray inspection?
    Safety is ensured through radiation leakage control (≤1μSv/h), transparent lead glass observation windows, safety interlock systems, electromagnetic safety switches, and an emergency stop button.
  • Can the X6800 perform automated inspections for batch processing?
    Yes, it supports programmable inspection procedures and automatic feature recognition, allowing for efficient automated batch inspection of multiple components.
  • What types of defects can the X6800 detect in electronic components?
    It can identify various defects including BGA solder bridges and voids, PCB through-hole issues, IC voids and gold wire cracks, LED solder voids, and capacitor or inductor faults.
